PET Geogrid
PET geogrid is made of polyester material, which has high strength and corrosion resistance, and is suitable for reinforced protection in civil engineering.
Product guide price: ＄0.99/㎡
PRODUCT DETAILS
Product Features
1、High strength
PET material has high tensile strength, which can effectively disperse loads and enhance soil stability.
2、Corrosion preventive
Resistant to acid, alkali, salt, and chemical solvent corrosion, suitable for complex geological environments.
3、Lightweight and flexible
Lightweight, easy to construct, and adaptable to foundation deformation.
4、Water permeability
The mesh structure allows water to pass through and reduces static water pressure.
Specification and technical indicators of PET Geogrid
| Item | RMPET TGSG50-50 | RMPET TGSG100-100 | RMPET TGSG150-150 | RMPET TGSG200-200 |
|---|---|---|---|---|
| Width | 2m, 4m, 6m (customizable according to customer needs, with a maximum width of 6m) | |||
| Length | 30m, 50m (customizable according to customer needs, unlimited length) | |||
| Mesh size (cell size) | 65mm (strip to medium size, including the width of one strip) | |||
| Colour | Black, Green | |||
| Ultimate tensile strength per linear meter in both longitudinal and transverse directions (kN/m) | ≥50 | ≥100 | ≥150 | ≥200 |
| Elongation rate% | ≤10 | |||
Note: The above product specifications can be customized according to customer needs. Please consult our sales engineers for specific technical parameters.
